PARTS REPLACEMENT INFORMATION GUIDE
CASING GROUP
Outer door
Blower door
Top filler plate
Bottom filler plate
Bottom enclosure
ELECTRICAL
GROUP
Control bracket
Junction box
Limit switch(es)
Circuit board
Door switch
Transformer
Wiring harness 115v
Wiring harness 24v
BLOWER
GROUP
Blower housing
Blower cutoff
Blower motor
Blower wheel
Grommet
Power choke (where used)
GAS CONTROL
GROUP
Manifold
Burner assembly
Orifice
Flame sensor
Hot surface igniter
Gas valv e
Manual reset limit switches
Burner support assembly
HEAT EXCHANGER
GROUP
Heat exchanger cell
Cell panel
Lox NOx baffle (California models only)
INDUCER
GROUP
Housing assembly
Pressure switch
Inducer motor
Inducer wheel
Vent elbow assembly
Draft safeguard switch
TO OBT AIN INFORMATION ON PARTS: Consult your installing dealer or classified section of your local telephone directory under
“Heating Equipment” or “Air Conditioning Contractors and Systems” headings for dealer listing by b rand name or contact:
PAYNE HEATING & COOLING
Consumer Relations Department
P.O. Box 4952
Syracuse, New York 13221 --4952
1--800 --417 --2963
Have available the model number, series number, and serial number located on the unit rating plate to ensure correct replacement part.
Example of Model Number
MODEL
COOLING CA-
PACITY
HEATING
CAPACITY
WIDTH SERIES VARIATIONS
PG80ESAA 36 070 A A A
