Mainboard User’s Manual
Mainboard Components
Use the diagram below to identify the major components on the
mainboard.
Note: Any jumper on your mainboard that do not appear in
the illustration above is for testing only.
CAUTION: Switching Power Supplier Limitation
The switching power supplier MUST support the specification as
the following table for AMD K7 CPUs.
CPU Athlon Duron
SPS 200W(min) 150W(min)
+5V
22A(min) 14A(min)
