Mainboard User’s Manual
Key Features
The key features of this mainboard include:
Socket-462 Processor Support
Supports AMD Athlon/Duron processors
Supports 200 MHz Front-Side Bus
Processors are automatically configured using firmware and a
synchronous Host/DRAM Clock Scheme.
Memory Support
Two DIMM slots for 168-pin SDRAM memory modules
Support for 100/133 MHz memory bus
Maximum installed memory is 2 x 512MB = 1GB
Expansion Slots
One AMR slot for a special audio/modem riser card
One optional AGP4X slot for AGP 2.0-compliant interface
Two 32-bit PCI slots for PCI 2.2-compliant bus interface.
Onboard IDE channels
Primary and Secondary PCI IDE channels
Support for PIO (programmable input/output) modes
Support for Multiword DMA modes
Support for Bus Mastering and Ultra DMA 33/66/100
modes
Power Supply and Power Management
ATX power supply connector
ACPI and previous PMU support, suspend switch,
keyboard power on/off
Supports Wake on Modem, Wake on LAN and Wake on
Alarm
