Mainboard User’s Manual
Load Best Performance Settings
If you select this item and press Enter a dialog box appears. If you
press Y, and then Enter, the Setup Utility loads a set of best-
performance default values. These default values are quite
demanding and your system might not function properly if you are
using slower memory chips or other low-performance components.
Features Setup Page
This page sets some of the parameters for peripheral devices
connected to the system.
AMIBIOS SETUP – PERIPHERAL SETUP
(C) 2000 American Megatrends, Inc. All Rights Reserved
OnBoard FDC Enabled
OnBoard Serial Port 3F8h/COM1
OnBoard IR Port Disabled
OnBoard Parallel Port 378h
Parallel Port Mode SPP
Parallel Port IRQ 7
Parallel Port DMA N/A
OnBoard Game Port 201h
OnBoard MIDI Port 300h
MIDI Port IRQ 10
OnBoard PCI IDE Both
AC’97 Sound Enabled
AC’97 Modem Auto
OnBoard LAN Enabled
USB Function Support Enabled
USB Function for DOS Disabled
ESC : Quit : Select Item
F1 : Help PU/PD/+/- : Modify
F5 : Old Values (Shift)F2 : Color
F6 : Load Optimal values
F7 : Load Best performance values
OnBoard FDC
Use this item to enable or disable the onboard
floppy disk drive interface.
OnBoard Serial
Port
Use this item to enable or disable the onboard
COM1 serial port, and to assign a port address.
OnBoard Ir Port
Use this item to define the protocol for an infrared
port if you have installed an optional IR port. The
choices are IrDA and ASKIR.
Onboard Parallel
Port
Use this item to enable or disable the onboard
LPT1 parallel port, and to assign a port address.
The Auto setting will detect and available address.
