Active to CMD (3T)
This item specifies the minimum required delay between activation
of different rows.
DRAM Burst Length (4)
This item describes which burst lengths are supported by the
devices on the mainboard. 1 level can provide faster performance
but may result in instability whereas 8 level gives the most stable
but slowest performance.
DRAM Queue Depth (4 level)
This item sets the depth of the DRAM queue used for CPU’s cache.
DRAM Command Rate (2T Command)
This item enables you to specify the waiting time for the CPU to
issue the next command after issuing the command to the DDR
memory. We recommend that you leave this item at the default
value.
Press <Esc> to return to the Advanced Chipset Setup screen.
AGP & P2P Bridge Control
This item has several sub-items:
AGP Aperture Size (128 MB)
This item defines the size of the aperture if you use an AGP
graphics adapter. The AGP aperture refers to a section of the PCI
memory address range used for graphics memory. We recommend
that you leave this item at the default value.
AGP Mode (4X)
This item allows you to enable or disable the caching of display
data for the processor video memory. Enabling AGP-4X Mode can
greatly improve the display speed. Disable this item if your
graphics display card does not support this feature.
AGP Driving Control (Auto)
This item is used to signal driving current on AGP cards to auto or
manual. Some AGP cards need stronger than normal driving
current in order to operate. We recommend that you set this
item to the default.
• AGP Driving Value: When AGP Driving Control
is set to Manual, use this item to set the AGP
current driving value.
Press <Esc> to return to the Advanced Chipset Setup screen.
