Mainboard User’s Manual
Parallel Port
Mode
Use this item to set the parallel port mode.
You can select SPP (Standard Parallel
Port), ECP (Extended Capabilities Port),
EPP (Enhanced Parallel Port), or ECP +
EPP.
Parallel Port
IRQ
Use this item to assign IRQ to the parallel
port.
Parallel Port
DMA
Use this item to assign a DMA channel to
the parallel port.
OnBoard
Game Port
This item enables or disables the I/O
address for the game port.
OnBoard MIDI
Port
Use this item to enable or disable the
onboard MIDI port, and to assign a port
address.
MIDI Port IRQ Use this item to assign IRQ 7 to the
parallel port.
OnBoard IDE Use this item to enable or disable the
onboard IDE channel.
OnChip LAN Use this item to enable or disable the
OnChip LAN.
OnBoard
AC’97 Audio
This item enables or disables the AC’97
audio chip.
OnBoard
MC’97 Modem
This item enables or disables the MC’97
modem chip.
USB
Controller
Use this item to select the USB ports or
disabled.
USB Device
Legacy
Support
This item allows you to enable the USB
device, if you have installed a USB device
on the system board.
ThumbDrive
Support For
DOS
Enable this item to make a small portion of
memory storage device for the USB ports.
