3: BIOS Setup Utility
Features Setup Page
This page sets up some parameters for those peripheral devices
connected to the system.
AMIBIOS SETUP – FEATURES SETUP
(C) 2000 American Megatrends, Inc. All Rights Reserved
OnBoard FDC Disabled
OnBoard Serial PortA 3F8h/COM1
OnBoard Serial PortB 2F8h/COM2
Serial Port2 Mode Normal
OnBoard IR Port Disabled
OnBoard Parallel Port 378h
Parallel Port Mode SPP
Parallel Port IRQ 7
Parallel Port DMA N/A
OnBoard Game Port 201h
OnBoard MIDI Port 300h
MIDI Port IRQ 10
OnBoard IDE Both
OnChip LAN Disabled
OnBoard AC’97 Audio Enabled
OnBoard MC’97 Modem Auto
USB Controller All USB Port
USB Device Legacy Support Disabled
ThumbDrive Support for DOS Disabled
ESC : Quit : Select
Item
F1 : Help PU/PD/+/- : Modify
F5 : Old Values (Shift)F2 : Color
F6 : Load BIOS Defaults
F7 : Load Setup Defaults
OnBoard FDC Use this item to enable or disable the
onboard floppy disk drive interface.
OnBoard Serial
PortA
Use this item to enable or disable the
onboard COM1 serial port, and to assign a
port address.
OnBoard IR
Port
Use this item to enable or disable the
onboard infrared port, and to assign a port
address.
To Next Page
