PCchips M925 Series - Page 8

Mainboard User’s Manual
 One VGA port
 One parallel port
 One MIDI/game port
 Six USB ports (two backpanel ports, onboard USB headers
providing four extra ports)
 Audio jacks for microphone, line-in and line-out
BIOS Firmware
This mainboard uses AMI BIOS that enables users to configure
many system features including the following:
 Power management
 Wake-up alarms
 CPU parameters and memory timing
 CPU and memory timing
The firmware can also be used to set parameters for different
processor clock speeds.
Built-in Ethernet LAN
 Built-in 10BaseT/100BaseTX Ethernet LAN
 VT8233 integrates Fast Ethernet MAC and VT6103 LAN
PHY in compliance with IEEE802.3u 100BASE-TX,
10BASE-T and ANSI X3.263 TP-PMD standards
 In compliance with ACPI 1.0 and the Network Device
Class Power Management 1.0
 High Performance achieved by 100Mbps clock generator
and data recovery circuit for 100Mbps receiver
Bundled Software
 PC-Cillin 2000 provides automatic virus protection under
Windows 98/ME/NT/2000/XP
 MediaRing Talk provides PC to PC or PC to Phone
internet phone communication
 3Deep delivers the precise imagery and displays accurate
color in your monitor
 Recovery Genius 21
st
V5.0 provides the function to
recover, reserve and transfer hard disk data.
 CD Ghost is the software stimulating a real CD-ROM to
perform equivalent function.
4
