2: Mainboard Installation
Chapter 2
Mainboard Installation
To install this mainboard in a system, please follow these
instructions in this chapter:
 Identify the mainboard components
 Install a CPU
 Install one or more system memory modules
 Make sure all jumpers and switches are set correctly
 Install this mainboard in a system chassis (case)
 Connect any extension brackets or cables to connecting
headers on the mainboard
 Install other devices and make the appropriate connections to
the mainboard connecting headers.
Note:
1. Before installing this mainboard, make sure jumper JBAT1 is
under Normal setting. See this chapter for information about
locating JBAT1 and the setting options.
2. Never connect power to the system during installation;
otherwise, it may damage the mainboard.
