Mainboard User’s Manual
Hardware Monitor Page
This page sets up some parameters for the hardware monitoring
function of this mainboard.
AMIBIOS SETUP – HARDWARE MONITOR
(C) 2000 American Megatrends, Inc. All Rights Reserved
*** System Hardware ***
Vcore 1.632V
Vcc 2.5V 2.496V
Vcc 3.3V 3.392V
Vcc 5V 4.945V
+12V 12.032V
-12V -11.968V
SB5V 5.026V
VBAT 3.488V
SYSTEM Fan Speed 0 RPM
CPU Fan Speed 1308 RPM
Power Temperature 33°C/91°F
SYSTEM Temperature 39°C/102°F
CPU Temperature 62°C/143°F
ESC : Quit ↑↓←→ : Select
Item
F1 : Help PU/PD/+/- : Modify
F5 : Old Values (Shift)F2 : Color
F6 : Load BIOS Defaults
F7 : Load Setup Defaults
CPU / System
Temperature
These items display CPU and system
temperature measurement.
FANs &
Voltage
Measurements
These items indicate cooling fan speeds in
RPM and the various system voltage
measurements.
Change Password
If you highlight this item and press Enter, a dialog box
appears that you can enter a Supervisor password. You can
enter no more than six letters or numbers. Press Enter after
you have typed in the password. There will be the second
dialog box asking you to retype the password for
confirmation. Press Enter after you have retyped it
correctly. Then, the password is required for the access to
the Setup Utility or for it at start-up, depending on the
setting of the Password Check item in Advanced Setup.
