1: Introduction
Built-in Graphics System
♦ P4M266/A integrates S3’s Savag4 graphics accelerator
into a single chip. P4M266/A brings mainstream graphics
performance to the Value PC with leading-edge 2D, 3D
and DVD video acceleration into a cost effective package.
Based on its capabilities, P4M266/A is an ideal solution
for the consumer, corporate mobile users and entry level
professionals.
♦ Maximum shared memory size is 32 MB.
VGA
♦ This mainboard includes a 4xAGP slot that provides four
times the bandwidth of the original AGP specification.
AGP technology provides a direct connection between the
graphics sub-system and memory so that the graphics do
not have to compete for processor time with other devices
on the PCI bus.
AC’97 Audio Codec
♦ Compliant with AC’97 2.1 specification
♦ 16-bit stereo full-duplex CODEC with fixed 48KHz
sampling rate
♦ 3 analog line-level stereo inputs with 5-bit volume control:
LINE-IN, CD-IN, AUX-IN
♦ 1 analog line-level mono input: PHONE-IN
♦ Three Audio Jacks – Line-Out, Line-In and Microphone-In
♦ Sound Blaster, Sound Blaster Pro Compatible
♦ Digital I/O compatible with consumer mode S/PDIF
♦ Advanced power management support
3
