FMX-003_UM_9752020820_NL_D_GB_F_V2_0 29
GB
4. Technical specifications
Power supply: 9 V DC alkaline battery, ICE code 6LR61
(30 hours life time)
Measuring range:
0 - 1,49 kV, (Lo range)
1 - 20 kV, (Hi range)
Hysteresis range
1 - 1,5 kV
Ion balance
0 - 200 V
Measuring distance 25 mm (between FMX and object to be measured)
Response time: <1 second
Accuracy: ± 10 %
Polarity: Positive and negative
Measuring frequency: 5 times per second
Graphical display: Red
Blue
positive polarity
negative polarity
Precision
0,1 kV Lo range
1,5 kV Hi range
15 V ion balance
Numerical display:
. = 0 - ± 1,49 kV
Lo range
. = ± 1 - ± 20 kV
Hi range
= 0 - ± 200 V
Ion balance
Automatic switch-off: After 5 minutes
Buzzer: Beep sound will be heard during the following actions:
- Power on: one beep
- Power on with Auto Off feature disabled: [Depress
power button for more than 3 seconds] three beeps
- Auto power-off: short beeps at 1 second interval for 5
seconds before power off
- Over range: Continuous sound
Operating temperature: 10 - 40 °C
Relative humidity: 0 - 60%RH (non-condensing)
Housing: Conductive plastic (ABS)
Size: 123 mm (L) x 73 mm (W) x 25 mm (H)
Weight: 170g
The measuring accuracy is not affected by air ionization.
