PDC spas SYNERGY Series FX15 User Manual

Electrical Guidelines—Export Installaons
30
FORQUALIFIEDELECTRICIANREFERENCEONLY!
 Allinstallaonsandconneconsaretobeperformedbyaqualified,licensedelectricianonly
andinaccordancewiththeNaonalelectriccodeandallapplicablelocalregulaons.
Ensurepoweristurnedoffpriortomakinganyelectricalconnecons.
ATTENTIONELECTRICIAN:
Swim Spa Units must be installed with a Residual Current Device, RCD, (not supplied)
Having a rated operang residual current not seceding 30 mA in accordance with all applicable local codes.
Installaon of RCD varies among those manufacturers. Follow each manufacturer’s guidelines
to ensure proper operaon and protecon of swim spa occupants.
IMPORTANT:10Gauge(2.59mm)CopperWireMUSTBeUsed
TestRCDMonthlyandPriortoEachUse.
NEUTRAL
GROUND
LINE
STRAIN RELIEF
ConnecngPowertoSwimSpaPack(QUALIFIEDELECTRICIANONLY)
 Confirm the circuit being used for swim spa power is RCD protected either
at main panel box or at disconnect.
 Verify that power is off to outside disconnect / RCD.
 Determine how wire is to enter swim spa cabinet.
 Route wire into swim spa cabinet over to spa pack.
 Remove spa pack cover.
 Install appropriate strain relief into spa pack. (see photo above)
 Insert wire through strain relief, removing wire sheath as needed depending on
wire type.
 Strip insulaon from wire and insert wire into correct terminal on terminal block.
(see photo above)
 Replace spa pack cover.
 Refer to start up procedure in manual before turning power on.
