PDC spas SYNERGY Series FX15 User Manual

Electrical Guidelines—Export Installaons
15
Electrical Guidelines (60Hz) North America
28
FORQUALIFIEDELECTRICIANREFERENCEONLY!
 Allinstallaonsandconneconsaretobeperformedbyaqualified,licensedelectricianonly
andinaccordancewiththeNaonalelectriccodeandallapplicablelocalregulaons.
Ensurepoweristurnedoffpriortomakinganyelectricalconnecons.
ATTENTIONELECTRICIAN:
Swim Spa Units must be installed with a Class A 50 Amp Ground Fault Circuit Interrupter (not supplied)
in accordance with the Naonal Electric Code and all applicable local codes.
Installaon of GFCI varies among those manufacturers. Follow each manufacturer’s guidelines
to ensure proper operaon and protecon of swim spa occupants.
IMPORTANT:6GaugeCopperWireMUSTBeUsed
TestGFCIMonthlyandPriortoEachUse.
NEUTRAL
GROUND
LINE 1
LINE 2
STRAIN RELIEF
ConnecngPowertoSwimSpaPack(QUALIFIEDELECTRICIANONLY)
 Confirm the circuit being used for swim spa power is GFCI protected either
at main panel box or at disconnect.
 Verify that power is off to outside disconnect / GFCI.
 Determine how wire is to enter swim spa cabinet.
 Route wire into swim spa cabinet over to spa pack.
 Remove spa pack cover.
 Install appropriate strain relief into spa pack. (see photo above)
 Insert wire through strain relief, removing wire sheath as needed depending on
wire type.
 Strip insulaon from wire and insert wire into correct terminal on terminal block.
(see photo above)
 Replace spa pack cover.
 Refer to start up procedure in manual before turning power on.
