Installation
This section is not intended to be a step by step guide to installing the PDR, the systems are complicated instruments
and need to be installed by PDR approved technicians, however, this section includes key points to consider before
commencing installation.
The PDR IR BGA Rework Systems were introduced early 2000s and have been developed to be able to be upgraded
from a basic system without BGA alignment to the full system as seen below.
Typical Configuration includes:
 Focused IR Component Heating
 750-3000W Quartz IR PCB Preheater
 Precision XY PCB Table
 Precision Pick-up System, with Macro-Micro Z-movement and Rotation
 CCTV/Prism BGA Alignment
 Advanced Software Control with PDR T5 Controller and PDR ThermoActive V4/V5 Software Suite.
CCTV/Prism BGA Alignment
Pick-up System
Focused IR Component Heating
System
