Peak Performance PKC0RE - Installation Guide

INST
ALLATION
S
ome states or local governments may have regulations or laws that restrict the
use of anything that might impair the clear view of a license plate. Check local laws for
compliance.
F
or the Back-Up Sensor to be properly installed, it must be wired into the vehicle’s
taillight harness. If you are not comfortable or knowledgeable with 12-volt DC wiring, have
the system professionally installed.
T
hese instructions are only meant as a general guide due to the number of
dierent makes and models of vehicles. For vehicle-specic questions contact your vehicle’s
manufacturer.
Remo
ve the screws that hold the license plate to the vehicle.1.
Position the le
ft and right sensor mounting plates behind the license plate.2.
Insert the scr
ews through the license plate and the sensor mounting plates.3.
Install the scre
ws to secure the sensors to the vehicle.4.
POWER
POWER
RIGHT
LEFT
+
2
3
7
6
8
9
4
3
5
1
Legend
1. Contr
oller
2.
Positive (+) Wire from Reverse Light
3.
Wire Connector
4. R
everse Light
5. Negativ
e (-) Wire from Reverse Light
6. Negativ
e (-) Controller Power Wire (Black)
7. P
ositive (+) Controller Power Wire (Red)
8. Right Sensor
9. L
eft Sensor
