PCAN-USB (ISO) – User Manual
6 Technical Specifications
Supply
Supply voltage +5 V DC (via USB port)
Current consumption max. 200 mA
Connectors
PC USB plug type A
CAN Sub-D (m), 9 pins
Pin assignment according to CiA recommendation DS
102-1
PCAN-USB ISO: galvanic isolation up to 500 V
USB
Type USB 1.1
I/O address, IRQ Automatically assigned by the PC
CAN
Specification ISO 11898
High-speed CAN (up to 1 MBit/s)
2.0A (standard format) and 2.0B (extended format)
Controller Philips SJA1000T
Transceiver Philips PCA82C251
Environment
Operating temperature -40 – +85 °C
-40 – +185 °F
Storage temperature -40 – +100 °C
-40 – +212 °F
Relative humidity 15 – 90 %, not condensing
EMC EN 50081-1:1992 (PCAN-USB only)
EN 50082-1:1997 (PCAN-USB only)
EN 50081-2:1993 (PCAN-USB only)
EN 61000-6-2:1999 (PCAN-USB only)
EN 61000-6-1:2001 (PCAN-USB ISO only)
EN 61000-6-2:2001 (PCAN-USB ISO only)
EN 61000-6-3:2001 (PCAN-USB ISO only)
EN 61000-6-4:2001 (PCAN-USB ISO only)
EC directive 89/336/EEC
Continued on next page
