PCAN-USB – User Manual
26
6 Technical Specifications
Connectors
Computer USB plug type A
CAN D-Sub (m), 9 pins
Pin assignment according to specification CiA® 102
USB
Type USB 1.1, compatible with USB 2.0
CAN
Specification ISO 11898-2, High-speed CAN
2.0A (standard format) and 2.0B (extended format)
Bit rates 5 kbit/s - 1 Mbit/s
Controller NXP (Philips) SJA1000
Transceiver NXP (Philips) PCA82C251
Galvanic isolation PCAN-USB: none
PCAN-USB opto: up to 500 V
Supplying external
devices
PCAN-USB: D-Sub pin 1/pin 9; 5 V, max. 100 mA
PCAN-USB opto: D-Sub pin 1; 5 V, max. 50 mA
Not assigned at delivery
Termination none
Power supply
Supply voltage +5 V DC (via USB port)
Power consumption max. 200 mA
Continued on the next page
