Playback: Play back the wave recorded or saved.
Playback menu shows as follows:
Menu Setting Instruction
Playback Mode
FrameSet
Start frame
End frame
Cur frame
Interval
Turn the M knob to select the number of start frame to playback
(1 ~ 1000)
Turn the M knob to select the number of end frame to playback
(1 ~ 1000)
Turn the M knob to select the number of current frame to playback
(1 ~ 1000)
Turn the M knob to select the interval between played back frames
(1 ms ~ 1000 s)
Play mode
Loop
Once
Play back the wave continuously
Play back the wave just one time
Operate
Play
Stop
Begin to record
Stop recording
Fig. 51 Wave Playback
Storage: Save the current wave according to the start frame and end frame set.
Storage menu shows as follows:
Menu Setting Instruction
Storage
Mode
Frame Set
Start frame
Turn the M knob to select the number of start frame to
store (1~1000)
End frame
Turn the M knob to select the number of end frame to store
(1~1000)
Save Save the waveform record file to the internal memory
Load Load the waveform record file from the memory
-137-
