37.2. General Technical Specifications
37.2.1. Display
Display Type 8” Colored LCD (Liquid Crystal Display)
Display Resolution 800 (Horizontal) × 600 (Vertical) Pixels
Display Colors 65536 colors, TFT screen
37.2.2. Output of the Probe Compensator
Output Voltage (Typical ) About 5 V, with the Peak-to-Peak voltage equal to or greater than 1
MΩ of load.
Frequency (Typical ) Square wave of 1 KHz
37.2.3. Power
Mains Voltage 100~240 VAC RMS, 50/60 Hz, CAT II
Power Consumption < 18 W
Fuse 1 A, T grade, 250 V
Battery (optional) 7.4 V/8000 mAh
37.2.4. Environment
Temperature
Working temperature: 0°C ~ 40°C
Storage temperature: -20°C ~ 60 °C
Relative Humidity ≤ 90 %
Height
Operating: 3,000 m
Non-operating: 15,000 m
Cooling Method Natural convection
37.2.5. Mechanical Specifications
Dimension (W x H x D) 340 × 155 ×70 mm
Weight 1,9 kg
37.3. Interval Period of Adjustment:
One year is recommended for the calibration interval period.
38. Appendix
38.1. Appendix A: Enclosure
Standard Accessories:
* 2 Passive probe: 1.2 m, 1:1 (10:1)
* CD: x 1 (PC link application software)
* Power cord: 1pcs, up to the standards of the country in which it is used.
* USB cable
* User Manual: 1pcs
Options:
* Battery
-171-
