PeakTech 3430 User Manual

34
Cleaning the cabinet
Clean only with a damp, soft cloth and a commercially available
mild household cleanser. Ensure that no water gets inside the
equipment to prevent possible shorts and damage to the
equipment.
1.1 Input limit
Function
Terminal
Max. input limit
V DC
V/Ω + COM
1000 V DC
V AC
V/Ω + COM
750 V AC
Ω
V/Ω + COM
250 V AC/DC
µA/mA-Range AC/DC
µA/mA + COM
250 mA AC/DC
10 A-Range
10 A + COM
10 A AC/DC
.
)))
V/Ω + COM
250 V AC/DC
Frequency
V/Ω + COM
250 V AC/DC
Logic
V/Ω + COM
250 V AC/DC
1.2 General declaration
Pmax: Peak max. value
Pmin: Peak min. value
UL: Appears if the duty cycle is smaller than 5,0
%
OL: Appears if the duty cycle is bigger than 94,9%
