2.5.2 Frequency sweeping function:
Press【Sweep】 key to output frequency sweeping signal.
Start frequency setting:
Set the start frequency at 5 kHz
Press【Menu】key to light the “Start” letter, press【5】【kHz】.
End frequency setting:
Set the end frequency at 2 kHz
Press【Menu】key to light the “Stop” letter, press【2】【kHz】.
Sweeping time setting:
Set the sweeping time at 5 s
Press【Menu】key to light the “Time” letter, press【5】【s】.
Sweeping mode setting：
Set logarithm sweeping mode
Press【Menu】key, press【1】【N】.
Trigger sweep setting:
Press【Trig】key, the sweeping will end when reaching to the end point, each time you
press【Trig】key, the generator trigger sweep once. Press 【Sweep】key again to resume to
continuous sweep.
2.5.3. Burst function:
Set continuous frequency as 1kHz.
【Burst】key, output burst signal.
Repeated period setting:
Set repeated period as 5ms
【Menu】key, light “Period” character, press【5】【ms】.
Pulse count setting:
Set pulse count as 1
【Menu】key, light “Ncyc” character, press【1】【N】.
Start phase setting:
Set start phase as 180°.
【Menu】key, light “Phase” character, press【1】【8】【0】【°】.
Trigger burst setting:
Press【Trig】key to stop the output of burst, then each time you press【Trig】key, the generator
triggers a burst once. Press【Burst】key to resume continuous burst.
-34-
