5. Specifications
5.1. Output characteristics of channel A
5.1.1. Waveform characteristics:
Waveform types
16 types including sine, square, ramp, exponent,
noise and so on.
Waveform length
1024 points
Sampling rate
100 MSa/s
Amplitude resolution
8 bits
Harmonic distortion (1Vpp)
≤-40 dBc (<5 MHz)
≤-35 dBc (>5 MHz)
Total distortion of sine
≤0,5 % (20 Hz ~ 20 kHz / 20 Vpp)
Rising/Falling Edge time
≤35 ns, over shoot: ≤ 10 %
Duty cycle of Square
0,1 % ~ 99,9 %
Ramp symmetry
0,0 % ~ 100,0 %
5.1.2. Frequency characteristics:
Frequency range
Sine
P 4055
10 µHz ~ 3 MHz
P 4060
10 µHz ~ 20 MHz
Square
P 4055
10 µHz ~ 3 MHz
P 4060
10 µHz ~ 5 MHz
Others
10 µHz ~ 1 MHz
Resolution
10 µHz
Frequency accuracy
±50 ppm
5.1.3. Amplitude characteristics:
Amplitude range
open circuit load
<8 MHz
0 mVpp ~ 20 Vpp
>8 MHz
0 mVpp ~ 18 Vpp
50  load
<8 MHz
0 mVpp ~ 10 Vpp
>8 MHz
0 mVpp ~ 9 Vpp
Resolution
5 mVpp
for amplitude >2 Vpp
0,5 mVpp
for amplitude <2 Vpp
Amplitude accuracy
±(1% + 2 mVrms)
frequency is 1 kHz / > 5 mVrms
Amplitude flatness
±10%
Sine, compared to 1 MHz, 5 Vpp
Output impedance
50 typical
5.1.4. Offset characteristics:
Offset range
±10 V DC (open circuit load)
±5V DC (50  load)
Resolution
5 mV DC
Offset accuracy
±(1% + 20 mV DC)
5.1.5. Sweeping characteristics:
Waveform
16 kinds of waveforms including sine, square, ramp, etc.
Sweeping range
the start/end point can be set arbitrarily
Sweeping rate
50 ms ~ 500 s
Sweeping mode:
linearity, logarithm
Trigger source
internal continuous, external signal, manual trigger
-54-
