5.1.6. FM, AM, PM, PWM:
Carrier waveform
16 kinds of waveforms including sine, square, ramp, etc.
(PWM only for pulse)
Modulation waveform
16 kinds of waveforms including sine, square, ramp, etc.
Modulation frequency
40 mHz ~ 20 kHz
Frequency offset
P 4055
10 μHz ~ 3 MHz
P 4060
10 μHz ~ 20 MHz
Modulation amplitude depth
0%~120%
Phase offset
0°~360°
Pulse width deviation
0%~99%
5.1.7. FSK:
Carrier waveform
16 kinds of waveforms including sine, square, ramp, etc.
Modulation waveform
Square
FSK rate
40 mHz ~100 kHz
Hop frequency
P 4055
10 μHz ~ 3 MHz
P 4060
10 μHz ~ 20 MHz
Trigger source
Internal continuous, external signal
5.1.8. Burst:
Waveform
16 kinds of waveforms including sine, square, ramp
Repeated period
1 μs ~ 20 s
Pulse count
1 ~1000000
Start phase
0°~ 360°
Trigger source
Internal continuous, external signal, manual trigger
5.2. Sync-Output characteristics
Waveform characteristics:
Square, edge time
≤ 20 ns
Amplitude characteristics:
Compatibility of TTL, CMOS
low level < 0.3 V
high level > 4 V
5.2.1 Programmable interface:
USB device interface, of which the operation guide is on the CD attached with the generator.
5.3. Power amplifier
Input Signal
0 Vrms to 4.5 Vrms
Maximum output voltage
9 Vrms
Frequency bandwidth:
100 Hz ~ 10 kHz
Voltage Amplifier
Double
Maximum output power
10 W (load 8)
5.4. General characteristics
Power conditions
Voltage
100 ~ 240 V AC
Frequency
45 ~ 65 Hz
Power
< 20 VA
Environment conditions
Temperature
0 ~ 40 °C
Humidity
<80% RH
Operation characteristics
Fully keyboard operation, continuously adjust with adjusting knob.
Display mode
VFD fluorescence display screen.
Dimensions (WxHxD)
256 x 102 x 322 mm
Weight
1,5 kg
-55-
