25
4. Front View
1. LCD Display
2. L-C-switch
3. Transistor Jack
4. Resistance, Diode and Continuity Buzzer Input Terminal
5. Capacitance and Inductance Input Terminal
6. Small Value Capacitance and Inductance Jack
1.
2.
3.
6.
7.
8.
4.
5.
