Peavey 112 User Manual

12
Rated Power:
40 watts RMS into 8 ohms,
nominal @ 1 kHz, 120 VAC line
Power Consumption:
(Domestic)
75 watts, 60 Hz, 120 VAC
(Export)
75 watts, 50/60 Hz, 230 VAC
The following specs are measured
at 1 kHz with all controls preset at
5; "Modern" voicing:
Input Sensitivity:
Nominal Input Level (Modern):
-15.4 dBV‚ 170 mV RMS
Maximum Input Level:
7.04 dBV‚ 2.25 V RMS
Tape/CD Input:
(Stereo cable must be used)
Impedance: High-Z, 33k ohms
Nominal Input Level:
8.46 dBV‚
2.65 V RMS
Effects Loop:
Nominal send and return level:
7.23 dBV‚ 2.3 V RMS
Headphone Output:
Nominal Output Level:
235 mW into 8 ohms
(Disconnects internal speaker when used)
System Hum & Noise @
Nominal Input Level:
(Clean channel‚ 20 Hz to 20 kHz unweighted)
Greater than 72 dB below rated
power
Dimensions (H x W x D):
21.25" x 18.188" x 12.125"
(540 mm x 462 mm x 308 mm)
Weight:
37.0 lbs. (16.8 kg)
MAX 112
Rated Power:
60 watts RMS into 4 ohms,
nominal @ 1 kHz, 120 VAC line
Power Consumption:
(Domestic)
75 watts, 60 Hz, 120 VAC
(Export)
75 watts, 50/60 Hz, 230 VAC
The following specs are measured
at 1 kHz with all controls preset
at 5; "Modern" voicing, Master
Volume preset at 10:
Input Sensitivity:
Nominal Input Level (Modern):
-15.5 dBV‚ 168 mV RMS
Maximum Input Level:
7.04 dBV‚ 2.25 V RMS
Tape/CD Input:
(Stereo cable must be used)
Impedance: High-Z, 100 k ohms
Nominal Input Level:
-8.0 dBV‚
398 mV RMS
Effects Loop:
Nominal send and return level:
-10 dBV‚ 325 mV RMS
Headphone Output:
Nominal Output Level:
320 mW into 8 ohms
(Disconnects internal speaker when used)
System Hum & Noise @
Nominal Input Level:
(Clean channel‚ 20 Hz to 20 kHz unweighted)
Greater than 90 dB below rated
power
Dimensions (H x W x D):
24.125" x 21.188" x 13.125"
(613 mm x 538 mm x 334 mm)
Weight:
57.8 lbs. (26.2 kg)
MAX 115
MAX
®
Series Specifications

Peavey 112 Specifications

General

Brand	Peavey
Model	112
Category	Musical Instrument Amplifier
Language	English
