Peavey 112 User Manual

11
Rated Power:
15 watts RMS into 4 ohms,
nominal @ 1 kHz, 120 VAC line
Power Consumption:
(Domestic)
50 watts, 60 Hz, 120 VAC
(Export)
50 watts, 50/60 Hz, 230 VAC
The following specs are measured
at 1 kHz with all controls preset at
5; "Modern" voicing:
Input Sensitivity:
Nominal Input Level (Modern):
-12.4 dBV‚ 240 mV RMS
Maximum Input Level:
6.0 dBV‚ 2.0 V RMS
Tape/CD Input:
Impedance: High-Z, 1Meg ohms
Nominal Input Level:
5.60 dBV‚ 1.90 V RM
S
Headphone Output:
Nominal Output Level:
75 mW into 8 ohms
(Disconnects internal speaker when used)
System Hum & Noise @
Nominal Input Level:
(Clean channel‚ 20 Hz to 20 kHz
unweighted)
Greater than 78 dB below rated
power
Dimensions (H x W x D):
14.375" x 12.563" x 8.875"
(366 mm x 320 mm x 226 mm)
Weight:
17.5 lbs. (7.94 kg)
MAX 158
Rated Power:
20 watts RMS into 4 ohms,
nominal @ 1 kHz, 120 VAC line
Power Consumption:
(Domestic)
50 watts, 60 Hz, 120 VAC
(Export)
50 watts, 50/60 Hz, 230 VAC
The following specs are measured
at 1 kHz with all controls preset at
5; "Modern" voicing:
Input Sensitivity:
Nominal Input Level (Modern):
-15.4 dBV‚ 170 mV RMS
Maximum Input Level:
7.04 dBV‚ 2.25 V RMS
Tape/CD Input:
Impedance: High-Z, 1.1Meg ohms
Nominal Input Level:
8.79 dBV‚
2.75 V RMS
Headphone Output:
Nominal Output Level:
100 mW into 8 ohms
(Disconnects internal speaker when used)
System Hum & Noise @
Nominal Input Level:
(Clean channel‚ 20 Hz to 20 kHz unweighted)
Greater than 73 dB below rated
power
Dimensions (H x W x D):
17.653" x 15.375" x 11.188"
(449 mm x 391 mm x 285 mm)
Weight:
25.4 lbs. (11.5 kg)
MAX 110
MAX
®
Series Specifications

Peavey 112 Specifications

General

Brand	Peavey
Model	112
Category	Musical Instrument Amplifier
Language	English
