POWER LED (11)
Illuminates when AC power is being supplied to the amp.
POWER SWITCH (12)
Depress the switch to the “on” position. The red LED will illuminate indicating that power is being supplied to
the unit.
WARNING: THIS UNIT IS CONNECTED TO THE MAINS POWER, EVEN IF THE POWER SWITCH IS
A
OFF.
CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT AND
A
FULLY INSERT.
BACK PANEL FEATURES
EXTERNAL SPEAKER JACK (13)
A
Provided for connection of external speaker cabinet. Minimum total impedance is 8 ohms.
Disconnects internal speaker when used.
