Peavey Nano Vypyr User Manual

Back Panel
Specifications
1/4" MICROPHONE INPUT
1/4" high impedance microphone input. The microphone is routed internally to the output section of the
Nano Vypyr and not through the amps and effects.
MICROPHONE INPUT LEVEL
Adjusts the input sensitivity of the 1/4" microphone input.
EXPRESSION PEDAL INPUT
Input for the optional expression pedal. The expression pedal will take the place of the Morph control on
the top of the amplier so that you may control effects parameters in real time. The Wah effect is actually an
auto-wah effect until you plug in the expression pedal, at which time the pedal will operate the wah just like a
normal wah-wah pedal.
1/8" AUXILIARY INPUT
High impedance 1/8" input for outboard equipment such as MP3 players, drum machines or CD players.
1/8" HEADPHONE OUTPUT
Output for listening to your Nano Vypyr through headphones or earbuds. Be careful not to listen to the Nano
Vypyr at full volume or for extended times as this can lead to ear fatigue or even hearing loss.
AC/DC ADAPTER
The Nano Vypyr is equipped with the ability to run on 4 D cells. However, if you wish to use AC power, this is
where you would plug in the included AC adapter. When using the adapter, the battery will switch off.
WARNING: DO NOT USE ANY ADAPTER OTHER THAN THE INCLUDED NANO VYPYR ADAPTER.
SLEEP MODE: If no audio is detected for 10 minutes, the Nano Vypyr enters sleep mode to conserve
battery power. The display will ash "SL". To wake up the Nano Vypyr, press the tap tempo button.
LOW BATTERY WARNING: The Nano Vypyr monitors battery voltage and adjusts performance to maximize
battery life and sound quality. The display will ash "LB" to indicate low voltage. Replace the battery with
fresh D-cells for maximum performance.
POWER SWITCH
Switch to turn on/off your Nano Vypyr.
1
2
3
4
5
6
7
1 2 3 4 5 6 7
BATTERY: Use quality 4 x D-cell alkaline (type
ANSI 13A) (type #1)
POWER ADAPTER: Universal input voltage
(100-240vac) to 6VDC / 3A
*Use only specied power adapter
POWER AMPLIFIER: Class-D
7W continuous into internal 8Ω speaker
GUITAR PRE AMPLIFIER: High voltage
TransTube
®
guitar pre amp
INPUT IMPEDANCE: Guitar Input = 250KΩ
MICROPHONE INPUT = 150KΩ
AUXILIARY INPUT (stereo to mono) = 10KΩ
DIGITAL EFFECTS: 24-bit DSP engine
WEIGHT (with battery): 10 lbs / 4.53Kg
DIMENSIONS: W = 10.25” (26cm) H = 10.25”
(26cm) D = 9.75” (25cm)
