SPECIFICATIONS Versarray™ 112
Frequency response, 1 meter on-axis,
swept-sine in anechoic environment:
110 Hz to 20 kHz (±3 dB, with processing)
Usable low frequency limit
(-10 dB point):
85 Hz (with processing)
Power handling:
Low Frequency Section:
500 W continuous
1,000 W program
2,000 W peak
High Frequency Section:
80 W continuous
160 W program
320 W peak
Sound pressure level, 1 watt, 1 meter
in anechoic environment:
Low Frequency Section:
96 dB SPL, (2.83 V input)
High Frequency Section:
99 dB SPL, (4.0 V input for 16 ohm wiring;
2.0 V for 4 ohm wiring)
Maximum sound pressure level
(1 meter)*:
Low Frequency Section:
123 dB SPL continuous
129 dB SPL peak
130 dB SPL measured peak**
High Frequency Section:
118 dB SPL continuous
124 dB SPL peak
130 dB SPL measured peak***
*Note: This spec is for one module at 1 meter. A line
array of 6 units has much higher output at distance
due to line source effect where SPL falls of at 3 dB per
distance doubling rather than 6 dB.
**Note: This is measured using transient tone burst
signals with a crest factor of 12 dB, and over 4,000W of
power available.
***Note: This is measured using transient tone burst
signals with a crest factor of 12 dB, and over 1,200W of
power available.
Nominal Radiation Angle measured at
-6 dB point of polar response:
90 degrees Horizontal by 15 degrees
Vertical
(One module only, straight line array of more than 1
module narrows vertical dispersion accordingly)
Radiation angle measured at -6 dB
point of polar response:
500 Hz – 1.6 kHz:
Horiz. 120o +/- 55o
Vert. 117o +/- 75o
1.6 kHz - 5 kHz:
Horiz. 84o +/- 20o
Vert. 34o +/- 20o
5 kHz - 16 kHz:
Horiz. 94o +/- 5o
Vert. 15o +/- 3o
Directivity factor, Q (Mean):
19.78 +19.4, -17.4
Directivity index, Di (Mean):
11.44 dB +4.5 dB, -7.6 dB
Transducer complement:
Low Frequency Section:
1 x 12" Woofer,
1212-4 Neo Black Widow® 4" VC
Woofer, in a sealed box
High Frequency Section:
2 x 4.75 in. Ribbon Tweeters
Two RD™ 1.6 Peavey Ribbon Tweeters,
on a waveguide
Box tuning frequency (sealed):
Low Frequency Section: 100 Hz
Harmonic distortion*:
1W power
Second Harmonic:
200 Hz: 0.18 %
1 kHz: 0.15 %
4 kHz: 0.09 %
Third Harmonic:
200 Hz: 0.22 %
1 kHz: 0.48 %
4 kHz: 0.12 %
10W power
Second Harmonic:
200 Hz: 0.71 %
1 kHz: 0.73 %
4 kHz: 0.42 %
Third Harmonic:
200 Hz: 0.19 %
1 kHz: 0.74 %
4 kHz: 1.08 %
*Note: Distortion levels may be measurement setup
limited in some instances
Electroacoustic Crossover Point,
Peavey Active Digital Crossover:
(Applies to Digitool and VSX settings provided by Peavey)
Sub–Low Frequency:
120 Hz at 24 dB/octave
Low Frequency–High Frequency:
1800 Hz at 24dB/octave
Recommended active crossover
frequency region and slope:
Sub –Low Frequency:
125 Hz at 24 dB/octave LR
Low Frequency – High Frequency:
2000 Hz at 24 dB/octave LR
Time offset:
Low Frequency:
Ahead of tweeter by 0.073 ms
Impedance (Z):
Low Frequency:
Nominal: 8.0 Ω
Minimum: 6.5 Ω
Passive HF:
Nominal: 16 Ω or 4 Ω
Minimum: 13.6 Ω or 3.4 Ω
Input connections:
2x Neutrik® 4-pin Speakon® jack
Enclosure materials & finish:
18 mm 13-ply Baltic birch plywood
finished in black or white painted finish,
perforated steel grille finished in silver-
vein powder coat paint.
Mounting provisions:
Custom array brackets and hardware, and
a custom array angle adjustment system
are included with each module. Quick
release pins, and a crank-lift system co-
designed with Vermette specifically for
the Versarray system, are available as
accessories.
Dimensions (H x W x D):
Front:
14.06 in. x 25.25 in. x 11.75 in.
357 mm x 641 mm x 298 mm
Rear:
12.62 in. x 25.25 in. x 11.75 in.
321 mm x 641 mm x 298 mm
Net Weight:
54 lbs. (24.5 kg)
(includes two of the rigging coupling brackets)
Companion Subwoofers
(sold separately):
Versarray™ 118 Sub single 18"
Lo Max® woofer subwoofer
Versarray™ 218 Sub double 18"
Lo Max® woofer subwoofer
Optional Accessories:
Custom Vermette Lift, for flying arrays
(Peavey part number 00595760); Peavey
Array Fly Bar (Peavey part number
00584970) A Versarray™ subwoofer
stand mount pole (Peavey part number
00584860); 3 foot speaker cable, with 16
gauge 4 conductor wires with 4-pin to 4-pin
Neutrik connectors (Peavey part number
00585240); and Quick Release Positive
Lock Pins (Peavey part number 00594020
for a set of four) for array rigging.
