Figure 1. Figure 2.
Assembly Instructions
Your bike has been pre-assembled and requires only a few simple steps to get it
ready for you to ride:
1. Remove the outside carton after cutting the nylon bands and lift off the entire box
from the tray at the bottom. Carefully remove your bike from the bottom tray and
gently rest it in place with the kickstand down.
2. Remove all of the inside cardboard protection and bubble wrap.
3. Please locate and set aside the kit box containing the battery charger, pedals, and
tool kit.
4. Insert the handlebar stem into the frame of the bicycle. You may adjust the height
of the handlebars by moving the stem up or down to your comfort level. Place your
thumb on the black locking mechanism on top of the stem, push up and lift the lever
up exposing the adjustment screws (Figure 1).
