Pg. 8 Pg. 9
For Trail Tracker
Your bike has been pre-assembled and requires only a few simple steps to get
it ready for you to ride:
1. Remove the outside carton after cutting the nylon bands and lift off the entire box
from the tray at the bottom. Carefully remove your bike from the bottom tray and
gently rest it in place.
2. Remove all of the inside cardboard protection and bubble wrap.
3. Please locate and set aside the kit box containing the battery charger, pedals, and
tool kit.
4. Install the front wheel by aligning the brake and fork and tightening the axle nuts
with the 15 mm wrench provided with your kit. Make sure that the hooked washers
are on the outside of the fork and are properly secured.
If necessary, align the stem with the front wheel and tighten the top stem bolt
enough to hold the stem in place. Once the handlebars are aligned and the top bolt
make sure there is no play in the headset.
Be careful to not tighten the top bolt too much as the steering will feel rigid and slug-
gish.
Continue to page 10
Top Bolt
Side Bolt
Side Bolt
3
3
3
To Next Page
