5
SET UP INSTRUCTIONS
(All Floor Model Ovens)
1. Uncrate Oven
Check to be sure owners manual, pressure
inside.
2. Leg Installation
Mount legs on the side of the unit while blocked,
(refer to Figure 1) NOTE: Ovens can be lightened
leg has four mounting bolts, packed inside oven.
After completing Step 1, proceed to the other two
legs. (refer to Figure 2)
3. Direct Vent
divertor which must vent outside.
WARNING: Flue pipe must be higher than nearest
roof peak (refer to Figure 4).
Canopy Vent
(refer to Figure 5 on following page).
4. Gas Connection
Install pressure regulator to lead in pipe, rear of
oven.
CAUTION: The oven is piped with 3/4” NPT
therefore supply line cannot be smaller. If using
5. Purge Air Out of Gas Lines
Depress red button on Safety Pilot and hold until
pilot lights. Once lit, hold for 30 to 60 seconds for it
to remain lit. If pilot goes out during this procedure,
repeat. Once pilot is set, turn valve “ON,” turn
thermostat dial to 350° and burner will ignite.
Figure 1
Figure 2
Figure 3
Figure 4
10 feet
Flue Divertor
Flue Adapter
Flue Box
To Next Page
