PEERLESS CW61 - Proper Flue Box Connection for Stacking Units; Step 1: Mount Z Baffle; Step 2: Mount Flue Boxes; Step 3: Mount Flue Hat

7
PROPER FLUE BOX CONNECTION
FOR STACKING UNITS
Step 1

opening of TOP oven.
Step 2
Mount both Flue Boxes
and interconnect.
Step 3
Mount proper Flue Hat
and Utility connections.
Flue Opening

Heat Flow
Flue Opening
