INSTALLATION INSTRUCTIONS
Models CW41, CW61, CW100, C131, CW51
The installation must conform with local codes, or in the absence of local
codes, with the National Fuel Code, ANSI Z223.1/NPA 54, Or the National
Gas and Propane Installation Code, CSA B149.1 - Latest Edition.
(All Models)
The appliance should be connected ONLY to the type of gas for which it is
equipped. All equipment is adjusted at the factory. Check type of gas on the
serial plated in the compartment below the oven door.
1. Place oven in desired location and level, using adjustable legs.
Then properly tighten lock nuts. Refer to “Set up” Instructions on page 4.
NOTE: On all threaded connections the pipe joint compound must be
approved for using on Natural and Propane gases.
3. Canopies are set over ovens for ventilation purposes. A strong exhaust
fan may create a vacuum in the room and may interfere with the burner
performance, check with the fan “OFF”.
and ventilation air are not obstructed. Provisions for an adequate air
supply must also be provided. Do not obstruct the front of the unit just
below the oven door, as air for combustion enters here.
Minimum clearance for combustible and noncombustible construction.
6” from sides
6” from rear
No additional clearance from the side and back is required for service, as
the units are serviceable from the front.
4. Legs have been packed inside the oven. Legs screw into the pads under
the unit base with bolts provided.
