REPAIR PARTS
Table 13.3: General Repair Parts – PF-210 & PF-399
Description
Quantity
Required
Stock
Code
1 Panel, Jacket Front Door, with Ball Studs 1 54256
2 Lens for Jacket Front Door 1 54167
3 Display Module, Argus 852RC 1 54281
4 Gasket for Display Bracket 1 54153
5 Bracket for Display Module 1 PF2007-1
6 Hex Nut, #6-32 with Lockwasher 2 51553
7 Screw, #6-32 x 1/2" LG Phillips Head 2 5449
8
Flexible Gas Line – 1/2" – PF-210 1 54261
Flexible Gas Line – 3/4" – PF-399 1 54262
9 Gasket for Gas Line 1 54142
10 Manual Shut-off Valve, 3/4" NPT 1 54210
11 Screw, #10 x 1/2" LG Hex. Hd. 2 99992
12 Jacket, Lower Front Panel 1 PF6051
13
Jacket Side Panel – PF-210 1 54244
Jacket Side Panel – PF-399 1 54245
14 Bulk Head Fitting for Condensate Hose 1 54140
15 Gasket for Bulk Head Fitting 1 54134
16 Leg Leveler 4 5429
17
Coupling, 1" NPT Brass – PF-210 2 5534
Coupling, 1-1/2" NPT Brass – PF-399 2 5551
18
Nipple, 1" NPT x 14" LG Brass – PF-210 2 5557
Nipple, 1-1/2" NPT x 14" LG Brass – PF-399 2 5550
19
Elbow, 1" NPT Brass – PF-210 1 5558
Elbow, 1-1/2" NPT Brass – PF-399 1 5553
20
Tee, 1" NPT Brass – PF-210 1 5537
Tee, 1-1/2" NPT Brass – PF-399 1 5554
21
Nipple, 1" NPT x 3" Brass – PF-210 2 5559
Nipple, 1-1/2" NPT x 3" Brass – PF-399 2 5552
22
Reducing Bushing, 1" x 3/4" NPT Brass – PF-210 1 5539
Reducing Bushing, 1-1/2" x 3/4" NPT Brass – PF-399 1 5556
23 Shut-off Valve, 3/4" NPT Brass 1 50764
24 Nipple, 3/4" NPT x 16" LG Brass 1 5560
25 Convenience Outlet 1 54136
26 Hex. Nut, #8-32 with Lockwasher 4 51573
27
Control Module, 852MN – PF-210 1 54286
Control Module, 852MN – PF-399 1 54287
28 Switch, Round Toggle, 120 VAC 1 6049
29
Vent / Air Inlet Adapter, 3" – PF-210 1 54200
Vent / Air Inlet Adapter, 4" – PF-399 1 54201
30
Gasket, Vent Adapter, 3" – PF-210 1 54133
Gasket, Vent Adapter, 4" – PF-399 1 54217
31 Screw, #10 x 3/4" LG Phillips Pan Hd. Type A Zinc 6 5611
32
Vent Stub, 3" – PF-210 1 54221
Vent Stub, 4" – PF-399 1 54220
33
Heat Exchanger Outlet Collar, 3" – PF-210 1 5531
Heat Exchanger Outlet Collar, 4" – PF-399 1 5532
34 Condensate Neutralizer Assembly 1 54204
35 Condensate Receiver Assembly 1 54259
36 Blocked Vent Switch includes items 37 & 38 1 54260
37 3/16" ID Tubing x 12" Long 1 5563
38 90° Barbed Elbow Adapter Fitting 1 5564
– Wiring Harness, Power (Right Terminal Block) 1 PF7022
– Wiring Harness, Control (Left Terminal Block) 1 PF7021
– Wiring Harness, Gas Valve & Flame Sensor 1 PF7023
– Wiring Harness, Ground Wire 1 PF7024
– Push-on Terminal Block (Field Wiring) 10-pole 2 5450
– Push-on Terminal Block (Field Wiring) 6-pole 2 5547
– Ignition Cable 1 54115
– Relief Valve 1 50664
– Flue Sensor, 12kOhm Tasseron TSDZ0B0 1 54209
– Flue Sensor Grommet 1 54291
– Supply Sensor/Switch, 12kOhm Tasseron Kit 1 54299
– Return Sensor, 12kOhm Tasseron TSD00BS 1 54418
– Outdoor Sensor, 12kOhm Tasseron TSA00B4 1 54112
