Table 7.1: Boiler Ratings
✸ As an ENERGY STAR
®
Partner, PB Heat, LLC has determined that these firing rates meet the ENERGY STAR guidelines for energy efficiency.
✝ Top venting only.
✚
Nozzles for these firing rates not provided as standard equipment. Consult factory for price and availability.
✪ This firing rate can only be achieved with a Riello F-3 burner. See Table 5.3.
1 Burner input based on No. 2 fuel oil with a heating value of 140,000 Btu per gallon.
2 Net water ratings based on an allowance of 1.15.
3 Consult factory before selecting a boiler for installations having unusual piping and pickup requirements, such as intermittent system operation, extensive
piping systems, etc.
4 Heating Capacity and Annual Fuel Utilization Efficiency (AFUE) ratings are based on U.S. Government tests.
Chimney Size: 8" x 8" x 15 ft.
BOILER DIMENSIONS & RATINGS
Series WBV/WV™- water
Boiler
Model
Number
Input
Heating
Capacity
4
,
MBH Net Ratings
3
AFUE,
%
GPH¹ MBH Water
Water,
MBH² Water
WBV-03-060-W 0.60
✚✪
84 75 65 87.5
✸
WBV-03-085-W 0.85 119 104 90 86.2
WBV-03-105-W 1.05 147 126 110 85.0
WBV-04-095-W 0.95
✚
133 117 102 87.0
✸
WBV-04-125-W 1.25 175 151 131 85.4
WBV-04-150-W 1.50 210 180 157 85.1
WBV-05-175-W
✝
1.75 245 212 184 85.5
WBV-05-195-W
✝
1.95 273 235 204 85.0
Water
Content,
gal
Minimum
Stack
Draft
Required,
in. W.C.
11.75 -0.03
11.75 -0.04
11.75 -0.05
14.75 -0.03
14.75 -0.04
14.75 -0.05
17.75 -0.05
17.75 -0.06
SERIES WBV/WV™ BOILER RATINGS - WATER
Series WBV/WV™- steam
Boiler
Model
Number
Input
Heating
Capacity
4
,
MBH Net Ratings
3
AFUE,
%
GPH¹ MBH Steam
Steam
Sq. Ft.
Steam,
MBH² Steam
WBV-03-085-S
0.85 119 103 321 77 84.8
WBV-03-105-S
1.05 147 124 388 93 83.6
WBV-04-125-S
1.25 175 151 471 113 85.3
WBV-04-150-S
1.50 210 179 558 134 84.3
Water
Content,
gal
Minimum
Stack
Draft
Required,
in. W.C.
12.00 -0.04
12.00 -0.05
14.87 -0.04
14.87 -0.05
SERIES WBV/WV™ BOILER RATINGS - STEAM
1 Burner input based on No. 2 fuel oil with a heating value of 140,000 Btu per gallon.
2 Net steam ratings based on an allowance of 1.333.
3 Consult factory before selecting a boiler for installations having unusual piping and pickup requirements, such as intermittent system operation, extensive
piping systems, etc.
4 Heating Capacity and Annual Fuel Utilization Efficiency (AFUE) ratings are based on U.S. Government tests.
Chimney Size: 8" x 8" x 15 ft.
