REPAIR PARTS
8. REPAIR PARTS
Repair parts are available from your local PB Heat, LLC distributor or from Parts To
Your Door at 1 (610) 916-5380 (www.partstoyourdoor.com).
Note: Remember to include the boiler model number and serial number when ordering parts.
Table 8.1
Part numbers may be subject to change without notice.
*See Figures 2.1 & 2.2 on page 5 for boiler exploded view.
Item
No.*
Description
Additional
Information
Stock
Code
1
Block Assembly – Water – WBV-03( Open)
–
90190
Block Assembly – Water – WBV-04 (Open)
–
90191
Block Assembly – Water – WBV-05 (Open)
–
90192
Block Assembly – Water – WBV-03 (Closed)
–
90348
Block Assembly – Water – WBV-04 (Closed)
–
90349
Block Assembly – Steam – WBV-03 (Open)
–
90707
Block Assembly – Steam – WBV-04 (Open)
–
90708
2 Target Wall
–
50795
4 Swing Door Hinge
–
90538
5 Burner Mounting Plate Assembly
–
90158
–
Burner Mounting Plate Insulation
–
50794
6 Burner Mounting Plate Rope Seal
–
51211
7 Steel Cover Plate (Front) – Water
–
99812
8 Rubber Gasket (Front) – Water
–
51800
9
Tankless Coil – WBV-03 – Water
–
90637
Tankless Coil – WBV-04 – Water
–
90534
Tankless Coil – WV-05 – Water
–
90534
Tankless Coil – WBV-03 & 04 – Steam
–
PP-1011R
10 Flue Collector Plate Blanket Seal
–
90999
11 Flue Collector Cover Plate – WBV-03
–
90565
–
Flue Collector Cover Plate – WBV-04
–
90566
11A Top Outlet Flue Collector Plate – WV-05
–
90562
12 Rope Seal
–
51209
13 Rear Outlet Cover Plate
–
90563
14
Flue Collar Adapter – WBV-03 & 04 – Water
– 90568
Flue Collar Adapter – WBV-03 & 04 – Steam
– 90386
15
Jacket Assembly – Water – WBV-03
–
90291
Jacket Assembly – Water – WBV-04
–
90288
Jacket Assembly – Water – WV-05
–
90290
Jacket Assembly – Steam – WBV-03
–
90292
Jacket Assembly – Steam – WBV-04
–
90289
16 Steel Cover Plate (Rear)
–
90141
17 Rubber Gasket (Rear Section Plate)
–
51673
18 Flue Outlet Gasket
–
PP5011
–
Pressuretrol
–
51324
–
Drain Valve
–
50764
–
Relief Valve – Water
–
50501
–
Pop Safety Valve – Steam
–
50510
–
Insulation Hardware
–
91218
–
Limit Control, Beckett AquaSmart 7600A
–
50337
–
Immersion Well, Beckett 7600T
–
50341
–
Immersion Sensor, Beckett 7600P
–
50339
–
Limit Control with Sensor, Hydrolevel HydroStat 3250
–
50343
–
Immersion Well, Hydrolevel
–
50723
To Next Page
