- 14 -
_ Apply the brake when loading or unloading children.
_ WARNING do not add any matress.
PRODUCT PARTS
Check the package contents and contact our Customer
Service for any claim.
_ The PLIKO MINI stroller is composed of:
2 swivel or locking front wheel sets, 2 rear wheel sets,
basket, hood.
INSTRUCTIONS
1• OPENING: to open the stroller, unhook the left hand
side lever (fig_a), hold the handles and at the same
time lift the stroller.
Check that the stroller has opened properly by
ensuring that the side hooks are well secured (fig_b).
2• If the hooks are not secured properly, press the seat
downwards (fig_d) until they click into place. Finally,
press downwards on PUSH with your foot (fig_e).
3• ASSEMBLING: to mount the front wheels, firstly check
that the washer is present, as shown in the figure, then
lower lever A and slip wheel B on until it clicks into
place.
4• To mount the rear wheels connected by the brake
cable, place them with the brake facing externally
(fig_a).
WARNING: ensure the hooks have clicked into place, as
in figure b.
5• Finally, hook the central element of the brake cable
onto the chassis, ensuring it clicks into place, as in the
figure.
6• BASKET: to mount the basket, slip the loops over the
rear hooks 1 and 2 and the front hook 3 (fig_a).
ADJUSTING THE HANDLES: the height of the handles
can be adjusted. Press the little button behind the
handles and pull upwards. To lower the handles, do the
opposite (Fig. b).
7• SWIVEL WHEELS: In order to make the wheels swivel,
the lever (arrow 1) must be lowered. To secure the
wheels, move the lever to the opposite direction
(arrow 2). The rear wheels are fixed.
BRAKE: To set the brake on the stroller, lower the lever
on the rear wheel unit with your foot. To release the
brake, lift the lever (fig_b). When stationary, always
apply the brake.
8• HOOD: To fit the hood, click the fasteners onto the
appropriate points and button down the hood on the
rear of the stroller’s backrest (fig_a).
The hood can be set to 2 positions (fig_b), simply by
pulling it backwards or forwards.
9• 5-POINT SAFETY HARNESS: to fasten, insert the two
buckles of the waist strap (with attached shoulder
straps, arrow a) into the leg divider strap until they
click into place (arrow b). To unfasten them, press the
button which is situated in the centre of the fastener
(arrow c) and pull the waist strap outwards (arrow d).
10•To tighten the waist strap, pull on both sides in the
direction of the arrow. To loosen it do the opposite.
11• It is possible to set the safety harness at 3 different
heights, depending on how tall the child is. As the
child gets bigger, the harness must be moved to a
higher position.
12• To adjust the height of the safety harnesses, release
the two buckles on the rear of the backrest.
Pull the shoulder straps towards you (arrow a) until the
buckles are released and insert them in the backrest
loops (arrow b). Remove the shoulder straps from the
sack (arrow c) and insert them in the most appropriate
buckle (arrow d), then reattach the two buckles
behind the backrest (arrow e). The buckles are securely
attached when a click is heard (fig f).
13• LEG REST ADJUSTMENT: The leg rest can be set in 2
different positions. To lower the leg rest, pull the two
side levers downwards and at the same time lower the
leg rest. To raise the leg rest, push it upwards until it
clicks into position.
BACKREST ADJUSTMENT: The backrest can be set in 3
positions: To lower the backrest, lift the levers on both
sides at the same time and lower it, locking it in the
position required. To lift the backrest, push it upwards.
14• FOLDING UP: pull one lever followed by the second
lever upwards until you hear them click (fig_a); then,
hold the central handle (fig_b) and pull it upwards
until the stroller folds up.
When folded, the stroller will stand upright (fig_c).
15• CARRYING: The stroller can be conveniently carried
(with the front wheels set on stationary) by the central
handle (fig_a). It can also be carried by the side handle
(fig_b).
16• REMOVABLE LINING: to remove the lining from the
stroller, unhook the fasteners on the rear of the
backrest (fig_1), slip the fastener of the leg divider out
from under the seat (fig_2), loosen the two screws
(on both sides) using a screwdriver to keep the nut
fastened (fig_3),
17• unhook the elastic from the chassis (fig_4), unhook the
chassis (fig_5, see OPENING paragraph, point 1), slide
the sack off the chassis (fig_6),
18• slide the sack off the footboard (fig_7).
and pull the sack upwards (fig_8).
SERIAL NUMBERS
19• The Stroller PLIKO MINI has all the following
relevant information behind the backrest: product
name, date of manufacture and serial number.
This information is required for any complaints.
ACCESSORIES
20• COVER: practical cover (Fig. a).
RAIN CANOPY: can be applied to the hood (Fig. b).
MOSQUITO NETTING: can be fastened to the hood
(Fig. c).
21• TRAVEL BAG: practical duffle bag for transporting the
stroller by plane (fig_a).
UMBRELLA: practical umbrella to match (fig_b).
CUP HOLDER: may be attached to the mushroom
button on the frame of the stroller (Fig. c).
22• BAG: diaper-changing bag with pad for changing baby’s
diaper (fig_a).
FRONT BAR: applicable to the product (fig_b).
PADDED CUSHION for Peg Perego high chairs and
strollers. Winter side made with cozy matelassé jersey
and summer side made with 100% cotton (fig_c).
CLEANING AND MAINTENANCE
PRODUCT MAINTENANCE: protect from the weather:
water, rain, or snow; prolonged and continuous
exposure to bright sunlight may give rise to colour
changes of various different materials; store this
product in a dry place.
The maintenance have to be
regularly.
