Pego EASYSTEAM User Manual

Rev. 01-16 Page 29
MANUALE D’USO – USER MANUAL
INSTALLING THE OEM SERIES HUMIDIFIER
1. Extract the humidifier from its packaging keeping it in vertical
position, remove the nylon protective bag and check appliance
integrity.
2. Fasten the humidifier levelled above the cell or to a base by
inserting the fixing screws in the 4 holes of the support base (fig.
17).
Fig. 17
3. Connect the water discharge tube to the 25 mm diameter sleeve, fixing it with the provided strap
(fig. 18 and 19).
Fig. 18 Fig. 19
The discharge tube must not be throttled or
create pressures, if so, it is essential to insert a
vent on the discharge line as shown in the
example of fig. 20.
Fig. 20
Only connect the discharge with piping
suitable for temperatures not below 100°C,
with a diameter not below 25 mm; do not
exceed the height of the humidifier in any point.
NEVER WORK THE HUMIDIFIER IF THE DISCHARGE LINE IS NOT
CORRECTLY CONNECTED!
2.11
