Pego ECP202 EXPERT User Manual

Pag. 4
ECP 202 EXPERT – Parameters Abstract
Rev. 01-19
CE1
Duration of compressor ON time in the
case of faulty ambient probe
(emergency mode).
If CE1=0 the emergency mode in the
presence of error E0 remains disabled, the
compressor remains off and defrosting is
prevented in order to conserve the remaining
cold.
0 ÷ 240 min
0 = disabled
0 min
CE2
Duration of compressor OFF time in the
case of faulty ambient probe.
(emergency mode).
5 ÷ 240 min
5 min
doC
Compressor safety time for door switch:
when the door is opened the evaporator fans
shut down and the compressor will continue
working for time doC, after which it will shut
down.
0 ÷ 5 min
0 min
tdo
Compressor restart time after door
opening. When the door is opened and after
tdo time, it’s setted back the normal
functioning giving door open alarm (Ed)
If the door switch is closed and the light
stays on for a longer time than tdo light cell
alarm is signaled (E9).
With tdo=0 the parameter is disabled.
0 ÷ 240 min
0 = disabled
0 min
Fst
FAN shutdown TEMPERATURE
The fans will stop if the temperature value
read by the evaporator sensor is higher
than this value.
-45 ÷ +99 °C
+99 °C
Fd
Fst differential
1 ÷ +10 °C
2 °C
LSE
Minimum value attributable to setpoint.
-45 ÷ (HSE-1) °C
-45 °C
HSE
Maximum value attributable to setpoint.
(LSE+1) ÷ +99°C
+99 °C
AU1
Auxiliary/alarm relay 1 control
-6 (NC) = relay de-energised during stand-by.
-5 (NC) = Contact for casing element control
(AUX relay closed with compressor
output inactive).
-4 (NC) = pump down function (NC, see CHAP
5.16).
-3 (NC) = automatic auxiliary relay managed
by StA temp. setting with 2°C differential
(NC).
-2 (NC) = manual auxiliary relay controlled via
AUX key (NC).
-1 (NC) = alarm relay (NC).
0 = relay deactivated.
1 (NO) = alarm relay (NO).
2 (NO) =manual auxiliary relay controlled via
AUX key (NO).
3 (NO) = automatic auxiliary relay managed
by StA temp. setting with 2°C differential
(NO).
4 (NO) = pump down function (NO, see CHAP
5.16).
5 (NO) = free voltage contact for condensing
unit (AUX relay and compressor relay in
parallel).
6 (NO) = relay excited during stand-by.
-1
AU2
Auxiliary/alarm relay 2 control
(like AU1 )
5
StA
Temperature setting for auxiliary relay
-45 ÷ +99°C
0 °C
