ECP 202 EXPERT – Parameters Abstract
Rev. 01-19
LIST OF LEVEL 2 VARIABLES (Installer level)
VARIABLES
MEANING
VALUES
DEFAULT
F3
Fan status with compressor off
0 = Fans run continuously
1 = Fans only run when compressor is working
2 = Fans disabled
1
F4
Fan pause during defrost
0 = Fans run during defrost
1 = Fans do not run during defrost
1
F6
Evaporator fans activation for air
recirculation.
The fans activate for a time defined by F7 if they
have not started working for the F6 time. If
activation time coincides with the defrosting
time, end of defrosting is awaited.
0 – 240 min
0 = (function not activated)
0 min
F7
Evaporator fans duration for air
recirculation. Fans working time for F6
0-240 sec.
10 sec
dE
Sensor presence
If the evaporator sensor is disabled defrosts
are carried out cyclically with period d0:
defrosting ends when an external device
trips and closes the remote defrost contact
or when time d3 expires.
0 = evaporator sensor present
1 = no evaporator sensor
0
d1
Defrost type, cycle inversion (hot gas) or
with heater elements
0 = heating element
1 = hot gas
2 = heater with temperature control
0
dPo
Defrost at Power On
0 = disabled
1 = defrost at power-on (if possible)
0
dSE
Smart defrost
0 = disabled
1 = enabled
0
dSt
Smart defrost Setpoint (if dSE=1)
The counting of the time between the defrost
is incremented only if the compressor is ON
and the evaporator temperature is less than
dSt.
-30 ÷ 30 °C
1 °C
dFd
Display viewing during Defrost
0 = current temperature
1 = temperature at the start of the defrost
2 = “DEF”
1
Ad
Net address for connection to TeleNET
supervision system or Modbus
0 ÷ 31 (con SEr=0)
1 ÷ 247 (con SEr=1)
0
SEr
RS-485 communication protocol
0 = TeleNET protocol
1 = Modbus-RTU protocol
0
Bdr
Modbus baudrate
0 = 300 baud
1 = 600 baud
2 = 1200 baud
3 = 2400 baud
4 = 4800 baud
5 = 9600 baud
6 = 14400 baud
7 = 19200 baud
8 = 38400 baud
5
Prt
Modbus parity check
0 = none
1 = even
2 = odd
0
Ald
Minimum and maximum temperature
signalling and alarm display delay
0 ÷ 240 min
120 min
C1
Minimum time between shutdown and
subsequent switching on of the
compressor.
0 ÷ 15 min
0 min
CAL
Cold room sensor value correction
-10,0 ÷ +10,0 °C
0,0 °C
