Pego ECP202 EXPERT User Manual

Pag. 2
ECP 202 EXPERT – Parameters Abstract
Rev. 01-19
FUNCTION
PRESS
View set point
Change set point
+ /
Change menu “User level”
+ (3 seconds)
Return
+ (3 seconds)
Change menu “Installer level”
+ + (3 seconds)
Return
+ (3 seconds)
LIST OF LEVEL 1 VARIABLES (User level)
VARIABLES
MEANING
VALUE
DEFAULT
r0
Temperature difference compared to main SETPOINT
0,2 – 10,0 °C
2,0 °C
d0
Defrost interval (hours)
If d0 = 0 cyclical defrosts Off
0 ÷ 24 hours
4 hours
d2
End-of-defrost setpoint.
Defrost is not executed if the temperature read by the defrost
sensor is greater than d2. (If the sensor is faulty defrosting is
timed)
-35 ÷ 45 °C
15°C
d3
Max defrost duration (minutes)
1 ÷ 240 min
25 min
d7
Drip duration (minutes)
At the end of defrost the compressor and fans remain at
standstill for time d7, the defrost LED on the front panel
flashes.
0 ÷ 10 min
0 min
F5
Fan pause after defrost (minutes)
Allows fans to be kept at standstill for a time F5 after dripping.
This time begins at the end of dripping. If no dripping has been
set the fan pause starts directly at the end of defrost.
0 ÷ 10 min
0 min
A1
Minimum temperature alarm
Allows user to define a minimum temperature for the room
being refrigerated. Below value A1 an alarm trips: the alarm
LED flashes, displayed temperature flashes and the buzzer
sounds to indicate the problem.
-45÷(A2-1) °C
-45°C
A2
Maximum temperature alarm
Allows user to define a maximum temperature for the room
being refrigerated. Above value A2 an alarm trips: the alarm
LED flashes, displayed temperature flashes and the buzzer
sounds to indicate the problem.
(A1+1)÷99 °C
+99°C
tEu
Evaporator sensor temperature display
(displays nothing if dE =1)
Evaporator
temperature
read only
ENGLISH
