Pelican PCL3 - Installation Overview; Pre-Installation; Bypass Valve Installation

CONNECTION SIZE: 1"
MAX PRESSURE OPERATING: 80 PSI
MAX TEMPERATURE: 100
°
DO NOT SCALE DRAWING





P
Pelican
Water Systems
  
 
  
 5

OPTIONAL BYPASS
HOSE SPIGOTS
MENU
SET
SHUT OFF VALVES
**
** BACKWASH LINE TO BE PLUMBED TO A DRAIN
INSTALLATION DIAGRAM
CALCITE PCL3/PCL6

