pellenc FIXION - BEFORE FIRST USE

9
DESCRIPTION AND TECHNICAL CHARACTERISTICS
DESCRIPTION AND TECHNICAL CHARACTERISTICS
Max. tying capacity 25 mm (1 in)
Tying tool power voltage* 14,4 V
Charger power voltage refer to charger operating instructions
Charger average power 5 W
NiMH battery capacity 3,0 Ah
Charging time 12 hours
Tying capacity (without charge)* 9,000 to 12,000 ties
Tie material total length 200 m/reel approx. (656 ft)
Corresponding number of ties 1,550 ties approx.
Tying tool weight 900 g (2 lbs)
Weight of carried tool (belt unit)* 2 kg (4,4 lbs)
*(with specied battery)
BEFORE FIRST USE
- Take the belt unit and tying tool out of the case.
- Rotate reel holder 10, placed under battery pack 12, so that the tie outlet is located on the right or left-
hand side, depending on whether you are right or left handed.
- Set the belt length using the two buckles 15.
ADAPTATION FOR BATTERY P2000
From September 1996 (serial no. 2900001/U), there is no special procedure required for use of the FIXION
with the P2000 battery.
- Check that switch 11 is denitely in the “0” position.
- Install the P2000 battery, instead of the special battery 12.
- Your tool is ready for use.
Total vibration values (triax vector sum) determined in accordance
with EN 60745-1.
(Uncertainty K=1.5 m/s²)
a
h
<2.5 m/s² max.
Noise value measured according to the standard EN 60745-1
Sound power level measured
(Uncertainty K=3 dB)
L
WA
= 81 dB maximum
Level of acoustic pressure at the work station measured
(Uncertainty K=3 dB)
L
pA
= 70 dB maximum
