Pelonis PFS40A4BBB - Installation Instructions; Base Installation

INSTALLATION INSTRUCTIONS
Name of components
①
②
Considerate Hint:
Remove ①②parts from the
component before performing
installation.
Base Installation
Align the column with the
groove on the base and
fix them together using a
right-angle bolt.
Pole
Rear grill
Tighten
knob
Right-angle bolt
Base
Motor
Motor shaft
Install by
aligning
2
