Pelonis PFS40M2ABB - Product Identification and Assembly; Part Names

PART NAMES
 Page 5 
NO. Description
1 Front grille
2 Fan blade
3 Plastic nut
4 Rear grille
5 Motor shaft
6 Motor housing
7 Spinner
8 Internal Pole
9 Extension Pole
10
Height adjustment
ring
11 Stand
12
Cross base
connector
1 2 3
Tighten
Loosen
47
Fasten
5
6
8
9
10
11
12
NOTICE:
All the pictures in this manual are for explanation purpose only. Any
discrepancy between the real object and the illustration in the drawing
shall be subject to the real subject.
