Peloton ROW User Manual

15
|
MOVING THE PELOTON COMMERCIAL ROW AND STORING IT UPRIGHT
4
Press the monitor arm release button.
5
Carefully lower the monitor arm until it stops,
and then release the button. Slowly lift the
monitor arm until you hear a click. Conrm that
the monitor arm is locked into place before
attempting to move the Peloton Row.
WARNING: To avoid instability when stowing
the Row vertically, the monitor must be stored
with the monitor arm in the lowered position
shown.
WARNING: Fully tighten rail bolt during
assembly and before stowing upright to prevent
rail separation and risk of injury.
Click

Peloton ROW Specifications

General

Weight	156 lbs
Max User Weight	300 lbs
Connectivity	Bluetooth 5.0
Dimensions	2 ft (24 in) W
Footprint	8 ft x 2 ft
Power Requirements	100-240V ~50/60Hz
User Height Range	4'11" - 6'5"
Display	23.8-inch HD touchscreen
