PP60 TROUBLE SHOOTING MANUAL
8-5-2013
4 FLASHES: MISSED IGNITION
HOME
HOME
PAGE 6
UNPLUG UNIT, CLEAN FIREPOT AND MAKE SURE IT IS
INSTALLED CORRECTLY, CLEAN FIREBOX AREA, CLOSE FIRE-
BOX DOOR, FILL HOPPER, PLUG UNIT BACK IN AND TURN
UNIT ON.
AFTER A FEW
MINUTES, DID A
FIRE START?
REMOVE FEED
SYSTEM AND
CHECK FOR
OBSTRUCTIONS
SYSTEM IS
REPAIRED
IS THE AUGER
FEEDING
PELLETS INTO
THE FIREPOT?
YES
NO
MAKE SURE THE
HOPPER LID IS
CLOSED
IS THE IGNITER
GETTING HOT?
MAKE THE REPAIR BY
EITHER CLEANING OR
REPLACING THE
COMPONENT.
BAD
GOOD
BAD
CHECK THE
VACUUM SWITCH
CONNECTIONS
AND VACUUM
HOSE
YES
NO
IS THE IGNITER
IN THE PROPER
POSITION IN THE
FIREPOT?
YES
NO
YES
NO
To Next Page
