PressureMAT User Guide
Revision 1
Page 13/29
At the program menu, the BACK button may be pressed to return to the HOME screen or
SELECT/PROG button pressed with the desired menu selected. The appearance and functions
of the menus are as follows:
Input Viewing
At this screen the UP/DOWN arrows are used to select what value is displayed on the HOME
screen. Press the SELECT/PROG button to select what value appears on the home screen for
the respective channel. The “*” appears next to the current selection for HOME screen
display. In most case this will remain as the Pressure value. The Service Time is the number
of hours the system has been in service. Pressing the SELECT/PROG button will confirm a
change- UNTIL THIS IS DONE, A SETTING CHANGE IS NOT CONFIRMED. Pressing
the HOME or BACK button before confirming a setting change with the SELECT/PROG
button will escape from that program menu without saving changes made before confirming
the entry.
Channel X Input Viewing
> * Pressure 0.0 psi
Service Time XXXX hrs
[SELECT] home display value
Output Viewing
At this screen the UP/DOWN arrows are used to select what value is displayed on the HOME
screen. Press the SELECT/PROG button to select what value appears on the home screen on
the line under the respective channel. The “*” appears next to the current selection for HOME
screen display. The SP Signal is the milliamp output corresponding to the pressure reading.
Name which by default is blank can be programmed in the in the output programming menu.
Pressing the SELECT/PROG button will confirm a change- UNTIL THIS IS DONE, A
SETTING CHANGE IS NOT CONFIRMED. Pressing the HOME or BACK button before
confirming a setting change with the SELECT/PROG button will escape from that program
menu without saving changes made before confirming the entry.
Channel X Output Viewing
SP Signal 20.000 mA
> * Name
[SELECT] home display value
To Next Page
